Product Description
 |  |  | |
| Name | NU2311 | NU2311 | NU2311 |
| Brand | NTN | ISO | KOYO |
| Category | Bearings | ||
| BDI Inventory | 0.0 | ||
| Manufacturer Name | NTN | ||
| Minimum Buy Quantity | N/A | ||
| Weight / Kilogram | 2.5 | ||
| EAN | 4547359143621 | ||
| Product Group - BDI | B04144 | ||
| E | 104.5 mm 4.1142 in | ||
| F | 70.5 mm 2.7756 in | ||
| rs min | 2 mm 0.0787 in | ||
| r1s min | 2 mm 0.0787 in | ||
| Radial clearance class | CN | ||
| Mass (without HJ ring) | 2.5 kg | ||
| Dynamic load, C | 148 kN | ||
| Static load, C0 | 162 kN | ||
| Fatigue limit load, Cu | 19.8 kN | ||
| Nlim (oil) | 6,100 rpm | ||
| Nlim (grease) | 5,200 rpm | ||
| Min operating temperature, Tmin | -40 °C | ||
| Max operating temperature, Tmax | 120 °C | ||
| Characteristic cage frequency, FTF | 0.4 Hz | ||
| Characteristic rolling element frequency, BSF | 4.95 Hz | ||
| Characteristic outer ring frequency, BPF0 | 4.83 Hz | ||
| Characteristic inner ring frequency, BPFI | 7.17 Hz | ||
| da min | 64 mm 2.5197 in | ||
| da max | 69 mm 2.7165 in | ||
| db min | 72 mm 2.8346 in | ||
| Da max | 111 mm 4.3701 in | ||
| ra max | 2 mm 0.0787 in | ||
| r1a max | 2 mm 0.0787 in | ||
| Size (mm) | 55x120x43(mm) | 55x120x43(mm) | 55x120x43(mm) |
| Bore Diameter (mm) | 55(mm) | 55(mm) | 55(mm) |
| Outer Diameter (mm) | 120(mm) | 120(mm) | 120(mm) |
| Width (mm) | 43(mm) | 43(mm) | 43(mm) |
| d | 55 mm 2.1654 in | 55 mm 2.1654 in | 55 mm 2.1654 in |
| Fw | 70,5 mm 2.7756 in | 70.5 mm 2.7756 in | |
| D | 120 mm 4.7244 in | 120 mm 4.7244 in | 120 mm 4.7244 in |
| B | 43 mm 1.6929 in | 43 mm 1.6929 in | 43 mm 1.6929 in |
| C | 43 mm 1.6929 in | 43 mm 1.6929 in | 43 mm 1.6929 in |
| r min. | 2 mm 0.0787 in | 2 mm 0.0787 in | |
| r1 min. | 2 mm 0.0787 in | 2 mm 0.0787 in | |
| Weight | 2,17 Kg | 2.10 Kg | |
| Basic dynamic load rating (C) | 148 kN | 148 kN | |
| Basic static load rating (C0) | 162 kN | 162 kN | |
| (Grease) Lubrication Speed | 5 200 r/min | 4500 r/min |
