Product Description
 |  |  | |
| Name | 7311C | 7311C | 7311C |
| Brand | NACHI | KOYO | CYSD |
| Configuration | Single Row | ||
| Enclosure | Open | ||
| Bore Type | Cylindrical Bore | ||
| Bore Size | 55 mm 2.1654 in | ||
| Outside Diameter | 120 mm 4.7244 in | ||
| Width | 29 mm 1.1417 in | ||
| Fillet Radius/Chamfer | 2 mm 0.0787 in | ||
| r1 | 1 mm 0.0394 in | ||
| a | -4.4 mm -0.1732 in | 26.4 mm 1.0394 in | |
| Dynamic Load Rating | 87,000 N | ||
| Static Load Rating | 60,000 N | ||
| Limiting Speed - Grease | 9,100 rpm | ||
| Limiting Speed - Oil | 13,000 rpm | ||
| da1 (min) | 65 mm 2.5591 in | ||
| da2 (min) | 65 mm 2.5591 in | ||
| Da1 (max) | 110 mm 4.3307 in | ||
| Da2 (max) | 114 mm 4.4882 in | ||
| ra (max) | 2 mm 0.0787 in | ||
| ra1 (max) | 1 mm 0.0394 in | ||
| Size (mm) | 55x120x29(mm) | 55x120x29(mm) | 55x120x29(mm) |
| Bore Diameter (mm) | 55(mm) | 55(mm) | 55(mm) |
| Outer Diameter (mm) | 120(mm) | 120(mm) | 120(mm) |
| Width (mm) | 29(mm) | 29(mm) | 29(mm) |
| d | 55 mm 2.1654 in | 55 mm 2.1654 in | 55 mm 2.1654 in |
| D | 120 mm 4.7244 in | 120 mm 4.7244 in | 120 mm 4.7244 in |
| B | 29 mm 1.1417 in | 29 mm 1.1417 in | 29 mm 1.1417 in |
| C | 29 mm 1.1417 in | 29 mm 1.1417 in | 29 mm 1.1417 in |
| Angle (α) | 15 ° | 15 ° | 15 ° |
| a - | 4.4 mm 0.1732 in | ||
| r min. | 2 mm 0.0787 in | 2 mm 0.0787 in | 2 mm 0.0787 in |
| r1 min. | 1 mm 0.0394 in | 1 mm 0.0394 in | |
| da min. | 65 mm 2.5591 in | 65 mm 2.5591 in | |
| Da max. | 110 mm 4.3307 in | 110 mm 4.3307 in | |
| ra max. | 2 mm 0.0787 in | 2 mm 0.0787 in | |
| Weight | 1.45 Kg | 1.45 Kg | 1,43 Kg |
| Basic dynamic load rating (C) | 87 kN | 87 kN | |
| Basic static load rating (C0) | 60 kN | 60,5 kN | |
| (Grease) Lubrication Speed | 9100 r/min | 9300 r/min | 9400 r/min |
